Zigbee2MQTT Setup

Medium 30 min ~$25

Zigbee is fantastic for smart home - low power consumption, mesh networking, and devices that last years on one battery. Zigbee2MQTT gives you one USB dongle for all Zigbee devices - IKEA, Aqara, Sonoff, Philips Hue, everything.

Open Source

Zigbee2MQTT is open source! Check out the Zigbee2MQTT GitHub for documentation and supported devices.

🤔 Why Zigbee2MQTT?

Feature	Zigbee2MQTT	Manufacturer Hub (IKEA/Hue)
Price	~$25 (one time)	$40-70 per hub
Devices	2800+ from all brands	Only own brand
Local	✅ 100% local	⚠️ Often cloud
Open	✅ Open source	❌ Closed

🛒 What Do You Need?

Zigbee USB Coordinator

Model	Price	Recommendation
Sonoff Zigbee 3.0 USB Dongle Plus	$20-25	⭐ Best value
SLZB-06 (Ethernet)	$50	Best for range
Conbee II	$45	Good, but pricier

USB extension cable

ALWAYS use a USB extension cable (1-2m). WiFi and Zigbee interfere - distance helps!

⚙️ Installation

Home Assistant OS

1. Install Mosquitto MQTT broker

   Go to Settings → Add-ons → Add-on store

   Search “Mosquitto broker” → Install → Start

2. Create MQTT user

   Settings → People → Users → Add user

   • Username: mqtt
   • Password: (choose something secure)
   • Administrator: ❌ No

3. Add Zigbee2MQTT repository

   Settings → Add-ons → Add-on store → ⋮ (three dots) → Repositories

   Add:

   https://github.com/zigbee2mqtt/hassio-zigbee2mqtt

4. Install Zigbee2MQTT

   Search “Zigbee2MQTT” → Install (use edge version for latest features)

5. Find your USB dongle

   Settings → System → Hardware → All Hardware

   Find the path like:

   /dev/serial/by-id/usb-Silicon_Labs_Sonoff_Zigbee_3.0_USB_Dongle_Plus-if00-port0

6. Configure Zigbee2MQTT

   Click Zigbee2MQTT add-on → Configuration:

   serial:
     port: /dev/serial/by-id/usb-Silicon_Labs_Sonoff...
   mqtt:
     server: mqtt://core-mosquitto
     user: mqtt
     password: your-mqtt-password
   frontend:
     port: 8485

7. Start and open

   Click Start and open: http://homeassistant.local:8485

Docker

docker-compose.yml

services:
  mosquitto:
    container_name: mosquitto
    image: eclipse-mosquitto
    volumes:
      - ./mosquitto/config:/mosquitto/config
      - ./mosquitto/data:/mosquitto/data
    ports:
      - "1883:1883"
    restart: unless-stopped

  zigbee2mqtt:
    container_name: zigbee2mqtt
    image: koenkk/zigbee2mqtt
    volumes:
      - ./zigbee2mqtt/data:/app/data
      - /run/udev:/run/udev:ro
    devices:
      - /dev/ttyUSB0:/dev/ttyUSB0
    ports:
      - "8080:8080"
    environment:
      - TZ=Europe/London
    restart: unless-stopped

📡 Add Devices

1. Open Zigbee2MQTT web interface

2. Click “Permit join (All)” at top

3. Pair the device (see table below)

4. Device appears - give it a descriptive name

5. Click “Disable join” when finished

Pairing Instructions

Device	How to pair
Aqara sensors	Hold button 5 sec until LED blinks
IKEA bulb	Turn on/off 6 times quickly
IKEA remote	Hold pairing button 10 sec near battery
Sonoff switch	Hold button 5 sec
Philips Hue	Turn on/off 5 times (or use Hue Bluetooth app)

Note

Device must be close to coordinator during pairing (~2m). Afterwards you can move it.

🌐 Mesh Network Tips

Zigbee is a mesh network. Powered devices (routers) amplify the signal.

Routers vs End Devices

Type	Description	Examples
Coordinator	Your USB dongle	Sonoff Dongle
Router	Amplifies signal	Bulbs, smart plugs
End device	Only receives	Sensors (battery)

Pro tip: Smart bulbs as repeaters

Place smart bulbs/plugs strategically in your home. They act as repeaters and extend your network!

WiFi Interference

Zigbee and WiFi both use 2.4 GHz. Avoid problems:

• Set WiFi to channel 1 or 11
• Let Zigbee2MQTT choose channel automatically (default 11)
• Use USB extension cable for coordinator

🔧 Troubleshooting

Device won't pair?

1. Is “Permit join” enabled?
2. Reset the device (see manual)
3. Move closer to coordinator
4. Check coordinator isn’t too close to WiFi router

Device drops from network?

1. Poor signal - add more routers (smart bulbs/plugs)
2. Check battery on sensors
3. Try re-pairing the device

🛒 Recommended Devices

Sensors

Device	Price	Comment
Aqara door/window	$10	Super reliable, small
Aqara temperature	$12	Battery lasts 2+ years
Aqara motion	$15	Fast response

Switches & Bulbs

Device	Price	Comment
IKEA TRETAKT	$10	Cheap smart plug
Sonoff ZBMINI	$12	Fits behind light switch
IKEA TRÅDFRI bulb	$10	Good light, works as router
